FRAGMENTS
ARCHITECTURE/ LANDSCAPE/ INTERIOR/ DIGITAL/ INSTALLATION
ARCHITECTURE/ LANDSCAPE/ INTERIOR/ DIGITAL/ INSTALLATION
NOTATION
Brick wall pattern and Notation
Mexico City Hotel Design
Instructor: Florencia Pita
Spring 2023
Location: Calle Marsella 58, Juárez, Cuauhtémoc, 06600 Ciudad de México
Partner: Maggie Zou
Handwork: Resin and plaster casts, 3D print, painting, CNC cut
This project will focus on ‘Fragments’ or pieces, as we will begin with the minor architectural elements, namely the Brick. The Brick is a fragment of architecture; it carries such a rich and profound history and therefore represents a powerful potential for space, material, and landscape. We will research its history, advance it to its future, and find design innovations that will spring from this ancient fragment.
part1: brick pattern
part2: Hotel Design
BRICK WALL PATTERN
BRICK CHUNK
A-A SECTION RENDERING
ELEVATION
AXONOMETRIC VIEW RENDERING
GENERAL PLAN
TYPICAL PLAN
